QOB210 – Square D – 10 Amp Circuit Breaker

SKU qob210 Category
Availability: Some items may be in stock.
For current availability or a custom quote, please contact us at quote@amrocor.com.

Price:

$ 39.99

QOB210 – Square D – 10 Amp Circuit Breaker

SKU qob210 Category
Thumb
Thumb
Thumb
Thumb
Thumb
Thumb
Product Image
Product Image
Product Image
Product Image
Product Image
Product Image
Click image to view
Photo may not represent actual item. Refer to name and product specs for all details.
Price:

$ 39.99

Availability: Some items may be in stock.
For current availability or a custom quote, please contact us at quote@amrocor.com.

Description

QOB210 – Square D Bolt-On Circuit Breaker

Square D QOB series single phase double pole 10 ampere bolt-on molded case circuit breaker with maximum voltage rating of 120V tripping method thermal magnetic and standard interrupting of 10 kiloampere at 120V functions long-time and instantaneous.

Specifications:

  • Product: Miniature circuit-breaker
  • Range: QO
  • Line Rated Current: 10 A
  • System Voltage: 120 V AC, 120/240 V AC, 48 V DC
  • Mounting Type: Bolt-on
  • Number of Poles: 2P
  • Circuit Breaker Type: Standard
  • Ratings: Not rated
  • Electrical Connection: Pressure plate
  • Number of Panel Spaces: 2
  • Wire Size: AWG 14…AWG 8 (copper or aluminium)
  • Height: 3 in
  • Depth: 2.91 in
  • Width: 1.5 in
  • Ambient Rating: 104 Degree F (40 Degree C)
  • Authentic Schneider Electric / Square D Product
  • Dimensions (H x W x L): 3″ x 1.5″ x 2.91″

Alt model: q0b210
