This 100 kVA Single-Phase Pad-Mount Transformer efficiently steps down 13200Y/7620V to 120/240V, making it ideal for commercial, utility, and light industrial distribution networks. Its dead-front, loop-feed design enhances safety and supports underground installations, while ONAN cooling ensures reliable, long-term operation. The durable, tamper-resistant pad-mount enclosure is built for outdoor use, delivering dependable service in demanding environments.

Technical Specifications:

• Power Rating: 100 kVA

• Phase: Single Phase

• Primary Voltage: 13200Y/7620V

• Secondary Voltage: 120/240V

• Cooling: ONAN (Oil Natural Air Natural)

• Configuration: Dead Front, Loop Feed

• Mounting Type: Padmount

• Insulation: Mineral Oil (optional FR3 fluid available from some manufacturers)

• Application: Commercial, Utility, Light Industrial

• Frequency: 60 Hz

• Certifications: ANSI C57.12.00 / C57.12.34

• Efficiency: Meets DOE 2016 energy efficiency standards

• Temperature Rise: 65 °C (common, may vary by build)
