15KVA 12470Y/7200 120/240 Single Phase Polemount Transformer

15 kVA Single Phase Pole-Mount Distribution Transformer

Primary: 12470Y/7200 V | Secondary: 120/240 V

Engineered for reliability and long-term performance, this 15 kVA Single Phase Pole-Mount Distribution Transformer is designed for overhead utility applications requiring high-efficiency voltage conversion from medium voltage to standard secondary service voltages. It is ideally suited for rural, residential, agricultural, and light commercial distribution networks.

Technical Specifications

• Power Rating: 15 kVA

• Primary Voltage: 12470Y/7200 V

• Secondary Voltage: 120/240 V

• Phase: Single Phase, 2-Winding

• Frequency: 60 Hz

• Insulation Level (BIL): 95 kV

• Impedance: In accordance with ANSI standards

• Cooling Class: ONAN (Oil Natural Air Natural)

• Mounting Configuration: Pole-Mounted

• Tank Finish: Corrosion-resistant powder-coated finish with stainless steel hardware

• Standards Compliance: ANSI C57.12.20, IEEE, NEMA, DOE Efficiency Standards

Features & Benefits

• Durable Construction: Heavy-duty steel tank with welded seams ensures rugged performance in harsh environments.

• High-Efficiency Core: Optimized silicon steel core provides reduced no-load losses and improved energy efficiency.

• Overhead Distribution Ready: Compact pole-mount design facilitates rapid deployment in standard utility infrastructure.

• Safety and Reliability: Integral pressure relief valve, drain valve, and protective devices ensure safe and dependable operation.

• Environmentally Compliant: Filled with high-grade mineral oil or optional biodegradable FR3 fluid.

Applications

• Overhead utility distribution

• Rural and remote residential service

• Agricultural and irrigation systems

• Light commercial power delivery

For use in critical utility infrastructure, this 15 kVA pole-mounted transformer delivers dependable power transformation with low maintenance requirements and superior field performance.
