15KVA 13200y/7620 120/240 Single Phase Polemount Transformer

15 kVA Single Phase Pole-Mount Distribution Transformer

Primary: 13200Y/7620 V | Secondary: 120/240 V

Engineered for performance and reliability, this 15 kVA Single Phase Pole-Mount Distribution Transformer is designed for overhead utility and rural distribution networks. With a 13200Y/7620V primary and a 120/240V secondary, it is ideal for stepping down medium voltage to standard service voltages in residential, agricultural, and light commercial settings.

Technical Specifications

• Power Rating: 15 kVA

• Primary Voltage: 13200Y/7620 V

• Secondary Voltage: 120/240 V

• Phase: Single Phase, 2-Winding

• Frequency: 60 Hz

• Insulation Level (BIL): 95 kV

• Impedance: Per ANSI standards

• Cooling Class: ONAN (Oil Natural Air Natural)

• Mounting Type: Pole-Mounted

• Tank Coating: Corrosion-resistant powder coating with stainless steel hardware

• Compliance: ANSI C57.12.20, IEEE, NEMA, DOE Efficiency Standards

Key Features

• Rugged Construction: Durable welded steel tank designed for long-term outdoor service

• High-Efficiency Core: Low-loss core construction for reduced energy waste

• Utility Ready: Optimized for overhead installation in standard pole-mount configurations

• Integrated Safety: Pressure relief device, drain valve, and grounding provisions included

• Eco-Compatible Options: Available with mineral oil or eco-friendly FR3 fluid

Applications

• Overhead distribution systems

• Rural and residential power service

• Agricultural and irrigation power needs

• Light commercial installations

Built to industry standards and field-proven for reliability, this 15 kVA pole-mount transformer is an essential component in modern power distribution networks.
