167KVA 13800V Delta to 2400V Single Phase Polemount Transformer

SKU AM228-1-1-1-1-1-1-1-1-2-1 Category
Availability: Some items may be in stock.
For current availability or a custom quote, please contact us at quote@amrocor.com.

Price:

$ 15,500.00

167KVA 13800V Delta to 2400V Single Phase Polemount Transformer

SKU AM228-1-1-1-1-1-1-1-1-2-1 Category
Thumb
Thumb
Thumb
Thumb
Thumb
Thumb
Product Image
Product Image
Product Image
Product Image
Product Image
Product Image
Click image to view
Photo may not represent actual item. Refer to name and product specs for all details.
Price:

$ 15,500.00

Availability: Some items may be in stock.
For current availability or a custom quote, please contact us at quote@amrocor.com.

Description

The 167 kVA Polemount Transformer steps down 13800V Delta to 2400V, providing reliable power distribution for industrial systems. With mineral oil cooling and an ONAN design, it ensures smooth, efficient operation. This transformer is built for long-lasting use, offering dependable performance for high-demand power systems.

Technical Specifications

  • Power Rating: 167 kVA

  • Primary Voltage: 13800V Delta

  • Secondary Voltage: 2400V

  • Cooling Class: ONAN (Oil Natural Air Natural)

  • Mounting Type: Polemount

  • Insulation Fluid: Mineral Oil

  • Compliance: ANSI, NEMA, DOE Efficiency Standards

Key Features

  • Heavy-Duty Construction: Steel tank designed for corrosion resistance

  • Efficient Performance: Low-loss transformer core for reliable energy distribution

  • Polemount Installation: Ideal for overhead applications

  • Safety Features: Equipped with pressure relief valve and grounding provisions

Applications

  • Industrial and commercial power systems

  • High-voltage power distribution

  • Overhead systems in urban and rural locations
