Applications:
SER is type SE, Style R cable, used as an above ground service entrance cable, a panel feeder and in branch circuits. The cable is rated at 600 volts and 90_C for use in wet and dry locations. SER cables are LEAD FREE and RoHS compliant.

Construction:
Conductor – Compact stranded AA-8000 series aluminum alloy (ACM) per ASTM B801 or B836. #8 AWG is solid AA-8000 series aluminum alloy (ACM) per ASTM B800.
Insulation – Color coded cross-linked polyethylene (XLPE).
Assembly – Insulated conductors are cabled with the bare ground wire. A flame retardant fiberglass reinforced binder tape assembles the core in a circular configuration.
Jacket – Sunlight resistant, LEAD FREE, flame retardant, gray polyvinyl chloride (PVC) material.

Specifications*:

Insulated Conductor Size: 250 MCM (3 Conductors)
Bare Neutral Size: 3/0
Outside Diameter: 1.601 inches
Ampacity amps 230
Net Weight: 1.13 lbs/ft

*Data provided on this page is subject to change based on different manufacturers variances.
