350-350-350-2 Metal Clad (MC) Cable with Ground, Aluminum Armored, Stranded Aluminum Conductors

Applications:
Aluminum Conductor – Aluminum MC Cable is suitable for use in branch, feeder and service power distribution under high ambient temperature in commercial, industrial, institutional, casinos and multi-residential buildings; for power, lighting, control and signal circuits; in concealed or exposed installations; in environmental air-handling spaces per NEC 300.22; in places of assembly per NEC 518.4 and theaters per NEC 520.5; in aerial applications when attached to a messenger; for installation in cable tray and approved raceways; under raised floors for IT equipment per NEC 645.5(D) and 645.5(D)(2); Class I Div 2, Class II Div 2, Class III Div 1 hazardous locations.

Conductors:
Aluminum MC Cable has a compact strand 8000 series aluminum alloy conductors.

Insulation:
Aluminum MC Cable has color coded cross-linked polyethylene XHHW-2 or THHN/THWN-2 insulation. The cable ground is either bare or has green insulation. A binder tape is wrapped over the conductor assembly.

Armor:
Aluminum MC Cable has an overall aluminum interlocked armor.

Standards:
– UL 44, UL 1569 for type MC
– NEMA WC70
– IEEEE 1202 70,000 BTU vertical flame test
– ICEA S – 95-658
– Federal Spec A-A59544 (formerly J – C – 30B)

Specifications*:
Size: 350
Conductors: 3 + 1 Ground
Ground Size: 2 AWG
Outside Diameter: 2.020 inches
Weight: 1.59 lbs/ft
Ampacity: 280

*Data provided on this page is subject to change based on different manufacturers variances.
