50 kVA 13200Y/7620 Single Phase Pad-Mount Transformer

Categories ,
Availability: Some items may be in stock.
For current availability or a custom quote, please contact us at quote@amrocor.com.

Price:

$ 6,985.00

50 kVA 13200Y/7620 Single Phase Pad-Mount Transformer

Categories ,
Thumb
Product Image
Click image to view
Photo may not represent actual item. Refer to name and product specs for all details.
Price:

$ 6,985.00

Availability: Some items may be in stock.
For current availability or a custom quote, please contact us at quote@amrocor.com.

Description

This 50 kVA Single-Phase Pad-Mount Transformer steps down 13200Y/7620V to 120/240V with high efficiency, making it well-suited for commercial, utility, and light industrial distribution systems. Its dead-front, loop-feed configuration enhances operational safety, simplifies maintenance, and allows seamless integration into underground networks. Equipped with ONAN cooling, it delivers consistent, long-term performance, while its tamper-resistant pad-mount enclosure is engineered for reliable operation in demanding outdoor conditions.

Technical Specifications:

  • Power Rating: 50 kVA

  • Phase: Single Phase

  • Primary Voltage: 13200Y/7620V

  • Secondary Voltage: 120/240V

  • Cooling: ONAN (Oil Natural Air Natural)

  • Configuration: Dead Front, Loop Feed

  • Mounting Type: Padmount

  • Insulation: Mineral Oil (FR3 fluid optional)

  • Application: Commercial, Utility, Light Industrial

  • Frequency: 60 Hz

  • Certifications: ANSI C57.12.00 / C57.12.34

  • Efficiency: Meets DOE 2016 energy efficiency standards

  • Temperature Rise: 65 °C
