50KVA 13200y/7620 120/240 Single Phase Polemount Transformer

Description

50 kVA Single Phase Pole-Mount Distribution Transformer

Primary: 13200Y/7620 V | Secondary: 120/240 V

This 50 kVA Single Phase Pole-Mount Distribution Transformer steps down 13200Y/7620V to 120/240V, ideal for overhead utility and rural distribution systems. Designed for high-demand applications, it is perfect for large residential, agricultural, and light commercial power needs, providing reliable and efficient performance.

Technical Specifications

• Power Rating: 50 kVA

• Primary Voltage: 13200Y/7620 V

• Secondary Voltage: 120/240 V

• Phase: Single Phase, 2-Winding

• Frequency: 60 Hz

• Insulation Level (BIL): 95 kV

• Impedance: Per ANSI standards

• Cooling Class: ONAN (Oil Natural Air Natural)

• Mounting Type: Pole-Mounted

• Tank Coating: Corrosion-resistant powder coating with stainless steel hardware

• Compliance: ANSI C57.12.20, IEEE, NEMA, DOE Efficiency Standards

Key Features

• Heavy-Duty Construction: Welded steel tank for durability in harsh outdoor conditions

• Energy Efficient: Low-loss core design for optimized energy consumption

• Pole-Mount Configuration: Quick and easy installation for overhead systems

• Safety Features: Includes pressure relief valve, drain valve, and grounding provisions

• Eco-Friendly Options: Available with mineral oil or biodegradable FR3 fluid

Applications

• Large residential and rural power supply

• Agricultural and irrigation power needs

• Light commercial electrical distribution

This 50 kVA pole-mount transformer offers dependable and efficient power distribution, ensuring reliable service even in high-demand environments.
