6-6-6 Aluminum SER Cable w/ 6AWG Ground

SKU 6GCW1245 Category
Availability: Some items may be in stock.
For current availability or a custom quote, please contact us at quote@amrocor.com.

Price:

$ 2.97

6-6-6 Aluminum SER Cable w/ 6AWG Ground

SKU 6GCW1245 Category
Thumb
Product Image
Click image to view
Photo may not represent actual item. Refer to name and product specs for all details.
Price:

$ 2.97

Availability: Some items may be in stock.
For current availability or a custom quote, please contact us at quote@amrocor.com.

Description

Applications:
SER is type SE, Style R cable, used as an above ground service entrance cable, a panel feeder and in branch circuits. The cable is rated at 600 volts and 90_C for use in wet and dry locations. SER cables are LEAD FREE and RoHS compliant.

Construction:
Conductor – Compact stranded AA-8000 series aluminum alloy (ACM) per ASTM B801 or B836. #8 AWG is solid AA-8000 series aluminum alloy (ACM) per ASTM B800.
Insulation – Color coded cross-linked polyethylene (XLPE).
Assembly – Insulated conductors are cabled with the bare ground wire. A flame retardant fiberglass reinforced binder tape assembles the core in a circular configuration.
Jacket – Sunlight resistant, LEAD FREE, flame retardant, gray polyvinyl chloride (PVC) material.

Standards:
Meets UL 854 Service Entrance Cable

Specifications*:

Insulated Conductor Size: 6 AWG
Bare Neutral Size: 6 AWG (7)
Outside Diameter: 0.717 inches
Ampacity amps 60
Net Weight: .196 lbs/ft

*Data provided on this page is subject to change based on different manufacturers variances.
