75 KVA 13200y/7620 120/240 Single Phase Polemount Transformer

75 kVA Single Phase Pole-Mount Distribution Transformer

Primary: 13200Y/7620 V | Secondary: 120/240 V

This 75 kVA Single Phase Pole-Mount Distribution Transformer efficiently steps down 13200Y/7620V to 120/240V, making it ideal for high-demand overhead utility and rural distribution systems. Perfect for large residential, agricultural, and light commercial applications, this transformer ensures reliable, efficient power delivery.

Technical Specifications

• Power Rating: 75 kVA

• Primary Voltage: 13200Y/7620 V

• Secondary Voltage: 120/240 V

• Phase: Single Phase, 2-Winding

• Frequency: 60 Hz

• Insulation Level (BIL): 95 kV

• Impedance: Per ANSI standards

• Cooling Class: ONAN (Oil Natural Air Natural)

• Mounting Type: Pole-Mounted

• Tank Coating: Corrosion-resistant powder coating with stainless steel hardware

• Compliance: ANSI C57.12.20, IEEE, NEMA, DOE Efficiency Standards

Key Features

• Rugged Construction: Strong, welded steel tank designed for long-term outdoor exposure

• Energy Efficient: Low-loss core design for optimized energy distribution

• Pole-Mount Design: Easy and quick installation for overhead power systems

• Safety Features: Includes pressure relief valve, drain valve, and grounding provisions

• Eco-Friendly Fluid Options: Available with mineral oil or biodegradable FR3 fluid

Applications

• Large residential and rural power distribution

• Agricultural power supply

• Light commercial electrical distribution

This 75 kVA pole-mount transformer is engineered for superior efficiency, providing long-lasting, reliable power distribution for high-demand applications.
