MJL36800 – Square D – Molded Case Circuit Breaker

SKU MJL36800 Category
Availability: Some items may be in stock.
For current availability or a custom quote, please contact us at quote@amrocor.com.

Price:

Original price was: $ 11,882.00.Current price is: $ 5,138.99.

MJL36800 – Square D – Molded Case Circuit Breaker

SKU MJL36800 Category
Thumb
Thumb
Thumb
Thumb
Product Image
Product Image
Product Image
Product Image
Click image to view
Photo may not represent actual item. Refer to name and product specs for all details.
Price:

Original price was: $ 11,882.00.Current price is: $ 5,138.99.

Availability: Some items may be in stock.
For current availability or a custom quote, please contact us at quote@amrocor.com.

Description

Overview

Product Specifications – MJL36800 – Square D Powerpact Circuit Breaker

  • Category:

    Molded Case / 3-Pole

  • Connection:

    I-Line Style Plug-In

  • Type:

    MJL

  • Functions:

    LI – Long-Time and Instantaneous

  • Protection:

    Solid State

  • AIC Ratings:

    65kA@480V

Dimensions

  • Dimensions (HxWxD):

    12.86″ x 0.32″ x 8.27″

  • Weight:

    29 lbs

Standards

CSA Approved logo

Additional Details

  • FrameType:

    M Frame

  • Trip Unit Technology:

    Electronic, basic, ET 1.0

  • Line Rated Current:

    800

  • Mounting Mode:

    Unit Mount Lug

  • Breaking Capacity Code

    J

  • Electrical Connection:

    Lugs line / Lugs load

  • Continuous Current Rating:

    80%

  • Control Type:

    Toggle

  • AWG Gauge:

    3 x AWG 3/0…3 x 500 kcmil aluminium/copper

Product Description – MJL36800 – Square D Powerpact Circuit Breaker

Schneider Electric / Square D, Powerpact, type MJL, 3P, 3PH, 800A, 600V, 65kA@480V, UL listed, current limiting, feed-thru, complete with basic non-interchangeable 1.0 trip, LI – Long-Time and Instantaneous trip functions and line & load side lug terminals, solid state electronic, molded case circuit breakers.

Documentation

PDF Icon Catalogue

PDF Icon Data Sheet
