QOB320 – Square D Bolt-On 20 Amp Breaker

Square D Bolt-On Circuit Breaker 3-Pole circuit breaker has voltage rating of 240 VAC current rating of 20 Amps and short-circuit current rating of 10 kilo-Amps. Circuit breaker has interrupting current rating of 5 kilo-Amps at 48 VDC. The 3-Phase circuit breaker has three-spaces and mounting bolts to hold the breaker in place.

Specifications:

• Product: Miniature circuit-breaker
• Range: QO
• Line Rated Current: 20 A
• System Voltage: 120 V AC, 120/240 V AC, 240 V AC, 48 V DC
• Mounting Type: Bolt-on
• Number of Poles: 3P
• Circuit Breaker Type: Standard
• Ratings: HACR rated
• Electrical Connection: Pressure plate
• Number of Panel Spaces: 3
• Wire Size: AWG 14…AWG 8 (copper or aluminium)
• Ambient Rating: 104 Degree F (40 Degree C)
• Authentic Schneider Electric / Square D Product
• Dimensions (H x W x L): 3″ x 2.25″ x 2.91″
• 3 phase

Alt model: q0b320
