25KVA 12470Y/7200 120/240 Single Phase Polemount Transformer

25 kVA Single Phase Pole-Mount Distribution Transformer

Primary: 12470Y/7200 V | Secondary: 120/240 V

This 25 kVA Single Phase Pole-Mount Distribution Transformer is designed for overhead utility and rural distribution networks. With a 12470Y/7200V primary and a 120/240V secondary, it efficiently steps down medium voltage to standard service voltages, making it ideal for residential, agricultural, and light commercial applications.

Technical Specifications

• Power Rating: 25 kVA

• Primary Voltage: 12470Y/7200 V

• Secondary Voltage: 120/240 V

• Phase: Single Phase, 2-Winding

• Frequency: 60 Hz

• Insulation Level (BIL): 95 kV

• Impedance: Per ANSI standards

• Cooling Class: ONAN (Oil Natural Air Natural)

• Mounting Type: Pole-Mounted

• Tank Coating: Corrosion-resistant powder coating with stainless steel hardware

• Compliance: ANSI C57.12.20, IEEE, NEMA, DOE Efficiency Standards

Key Features

• Robust Construction: Heavy-duty steel tank for durability in harsh environments

• Energy-Efficient Core: Low-loss core to reduce energy waste and improve system efficiency

• Pole-Mount Design: Easy installation for overhead distribution systems

• Safety Features: Includes pressure relief valve, drain valve, and grounding provisions

• Eco-Friendly Fluid Options: Available with mineral oil or biodegradable FR3 fluid

Applications

• Overhead utility distribution systems

• Residential and rural power supply

• Agricultural and irrigation services

• Light commercial power applications

Built to deliver reliable and efficient performance, this 25 kVA pole-mount transformer is a trusted solution for high-demand power distribution.
