37.5KVA 480V 1PH to 120/240V Single Phase Polemount Transformer

SKU AM228-1-1 Category
Availability: Some items may be in stock.
For current availability or a custom quote, please contact us at quote@amrocor.com.

Price:

$ 8,300.00

37.5KVA 480V 1PH to 120/240V Single Phase Polemount Transformer

SKU AM228-1-1 Category
Thumb
Thumb
Thumb
Thumb
Thumb
Thumb
Product Image
Product Image
Product Image
Product Image
Product Image
Product Image
Click image to view
Photo may not represent actual item. Refer to name and product specs for all details.
Price:

$ 8,300.00

Availability: Some items may be in stock.
For current availability or a custom quote, please contact us at quote@amrocor.com.

Description

This 37.5 kVA Polemount Transformer steps down 480V 1PH to 120/240V, ideal for residential and light commercial systems. Equipped with a mineral oil cooling system, this transformer ensures reliable, efficient power delivery and a long operational life.

Technical Specifications

  • Power Rating: 37.5 kVA

  • Primary Voltage: 480V 1PH

  • Secondary Voltage: 120/240V

  • Cooling Class: ONAN (Oil Natural Air Natural)

  • Mounting Type: Polemount

  • Insulation Fluid: Mineral Oil

  • Compliance: ANSI, NEMA, DOE Efficiency Standards

Key Features

  • Durable Construction: Corrosion-resistant steel tank

  • Energy Efficient: Low-loss transformer core

  • Polemount Design: Easy installation for overhead distribution systems

  • Safety Features: Includes pressure relief valve and grounding provisions

Applications

  • Residential and small commercial power distribution

  • Overhead electrical systems in rural areas

  • Agricultural power systems
