Description

50 kVA Single Phase Pole-Mount Distribution Transformer

Primary: 12470Y/7200 V | Secondary: 120/240 V

This 50 kVA Single Phase Pole-Mount Distribution Transformer efficiently steps down 12470Y/7200V to 120/240V, ideal for overhead utility and rural distribution networks. Perfect for large residential, agricultural, and light commercial applications, it delivers reliable power for various electrical systems.

Technical Specifications

• Power Rating: 50 kVA

• Primary Voltage: 12470Y/7200 V

• Secondary Voltage: 120/240 V

• Phase: Single Phase, 2-Winding

• Frequency: 60 Hz

• Insulation Level (BIL): 95 kV

• Impedance: Per ANSI standards

• Cooling Class: ONAN (Oil Natural Air Natural)

• Mounting Type: Pole-Mounted

• Tank Coating: Corrosion-resistant powder coating with stainless steel hardware

• Compliance: ANSI C57.12.20, IEEE, NEMA, DOE Efficiency Standards

Key Features

• Durable Design: Robust welded steel tank for outdoor durability

• Energy Efficient: Low-loss core for enhanced energy savings

• Pole-Mount Ready: Easy installation for overhead utility systems

• Safety Features: Pressure relief valve, drain valve, and grounding provisions

• Eco-Friendly Options: Available with mineral oil or biodegradable FR3 fluid

Applications

• Large residential and rural power supply

• Agricultural and irrigation power needs

• Light commercial electrical distribution

This 50 kVA pole-mount transformer is built for reliable, efficient power distribution in high-demand environments, providing long-lasting service with minimal maintenance.
