75 kVA Single Phase Pole-Mount Distribution Transformer

Primary: 12470Y/7200 V | Secondary: 120/240 V

This 75 kVA Single Phase Pole-Mount Distribution Transformer steps down 12470Y/7200V to 120/240V, making it ideal for overhead utility, rural, and large residential distribution systems. Built for high-power applications, it provides reliable and efficient service for residential, agricultural, and light commercial needs.

Technical Specifications

• Power Rating: 75 kVA

• Primary Voltage: 12470Y/7200 V

• Secondary Voltage: 120/240 V

• Phase: Single Phase, 2-Winding

• Frequency: 60 Hz

• Insulation Level (BIL): 95 kV

• Impedance: Per ANSI standards

• Cooling Class: ONAN (Oil Natural Air Natural)

• Mounting Type: Pole-Mounted

• Tank Coating: Corrosion-resistant powder coating with stainless steel hardware

• Compliance: ANSI C57.12.20, IEEE, NEMA, DOE Efficiency Standards

Key Features

• Rugged Construction: Durable steel tank for long-term outdoor use

• Energy Efficient: Low-loss core design for cost-effective power distribution

• Pole-Mount Ready: Easy and quick installation for overhead systems

• Safety Features: Pressure relief valve, drain valve, and grounding provisions for added security

• Eco-Friendly Options: Available with mineral oil or biodegradable FR3 fluid

Applications

• Large residential and rural power distribution

• Agricultural and irrigation power needs

• Light commercial electrical distribution

This 75 kVA pole-mount transformer is engineered for high-efficiency, providing dependable power to meet demanding applications with minimal maintenance.
