167KVA 12470V Delta to 120/240V Single Phase Polemount Transformer

SKU AM228-1-1-1-1-1-1-1-1-2-1-1-1-1 Category
Availability: Some items may be in stock.
For current availability or a custom quote, please contact us at quote@amrocor.com.

Price:

$ 16,500.00

167KVA 12470V Delta to 120/240V Single Phase Polemount Transformer

SKU AM228-1-1-1-1-1-1-1-1-2-1-1-1-1 Category
Thumb
Thumb
Thumb
Thumb
Thumb
Thumb
Product Image
Product Image
Product Image
Product Image
Product Image
Product Image
Click image to view
Photo may not represent actual item. Refer to name and product specs for all details.
Price:

$ 16,500.00

Availability: Some items may be in stock.
For current availability or a custom quote, please contact us at quote@amrocor.com.

Description

The 167 kVA Polemount Transformer is designed to step down 12470V Delta to 120/240V, making it an ideal solution for residential, utility, and light commercial power distribution. With mineral oil cooling and ONAN design, this transformer offers efficient, reliable performance in overhead systems.

Technical Specifications

  • Power Rating: 167 kVA

  • Primary Voltage: 12470V Delta

  • Secondary Voltage: 120/240V

  • Cooling Class: ONAN (Oil Natural Air Natural)

  • Mounting Type: Polemount

  • Insulation Fluid: Mineral Oil

  • Compliance: ANSI, NEMA, DOE Efficiency Standards

Key Features

  • Durable Steel Tank: Designed to resist corrosion and ensure long-term reliability

  • Energy-Efficient Design: Low-loss core ensures optimal power delivery

  • Polemount Design: Perfect for overhead distribution applications

  • Safety Features: Includes grounding provisions and pressure relief valve

Applications

  • Residential power distribution

  • Utility and light commercial systems

  • Overhead distribution in urban and rural areas
